Product Introduction: Fuji Electric 2MBI1400VXB-120E-272 Dual IGBT Module | 1200V / 1400A | Renewable Energy & Industrial Applications
Overview
The 2MBI1400VXB-120E-54 is a high-performance, original Fuji Electric Power Module designed for demanding energy conversion systems. As part of Fuji’s V-Series PrimePACK™ portfolio, this 2-in-1 IGBT (Insulated Gate Bipolar Transistor) module integrates advanced semiconductor technology to deliver exceptional efficiency in solar/wind inverters, industrial UPS, and motor drives. Engineered with reliability under high-power operating conditions.
Key Features & Advantages
1. Optimized Power Architecture
- Voltage/Current Rating: 1200V / 1400A, ensuring robust handling of high-power surges and transient loads.
- Dual IGBT Configuration: 2-in-1 topology simplifies circuit design while minimizing conduction and switching losses.
2. V-Series PrimePACK™ M272 Packaging
- Enhanced Thermal Dissipation: Low thermal resistance design prolongs lifecycle under extreme thermal cycling.
- Low Parasitic Inductance: Optimized internal layout reduces EMI noise switching oscillations.
- Industry-Standard Form Factor: M272 mechanical compatibility enables easy integration into existing platforms.
- Original Fuji Silicon Technology: Precision-tested IGBT and diode chips ensure high ruggedness and avalanche tolerance.
- High-Frequency Operation: Supports up to 20 kHz switching, ideal for PWM-driven topologies in inverters and converters.
- DBC Substrate with AlN Insulator: Superior isolation and thermal conductivity enhance thermal shock resilience.
Targeted Applications
- Solar Photovoltaic Inverters: Centralized or string inverter stages (DC-ers**: Doubly fed induction generator (DFIG) or full-power inverter systems.
- Industrial UPS: High-efficiency three-phase conversion with minimal THD.
- Motor Drives: High-torque variable frequency drives (VFDs) for industrial machinery.
Technical Specifications Summary
| Parameter | Value |
|---------------------|---------------------------|
| Manufacturer | Fuji Electric |
| Model No. | 2MBI1400VXB-120E-54 |
| Module Type | Dual IGBT + Freewheeling Diode |
| Voltage (Vces) | 1200 V |
| Collector Current (Ic)| 1400 A (@Tc=80°C) |
| Package | PrimePACK™ M272 |
| Switching Support | Up to 20 kHz |
| Isolation Voltage | ≥2500 Vrms (UL certified) |
Why Choose Fuji PrimePACK™ V-Series?
- Proven Field Performance: Used in utility-scale renewable installations worldwide.
- Full Documentation & Support: Includes datasheets, thermal models, and application guides.
- Traceable Manufacturing: ISO/IEC quality managed production line for assured authenticity.
Safety Notice: Installation must comply with IEC/EN standards for high-voltage systems. Use recommended gate drivers and thermal interface materials to ensure rated performance.
For engineering documentation or BOM integration support, contact our technical team.
🚀 Accelerate Your Energy Project – Order Now for Bulk Pricing Options!
