Product Introduction: This module is a high-voltage module/generator made by using components to form circuits for high-voltage packages/transformers. It can be used as a high-voltage source for student science popularization experiments, electronic instruments, negative ion generators, and scientific small-scale production. The module is made using the Tesla coil principle, outputting high-voltage pulses, with a small volume, high efficiency, and strong discharge intensity.
Module model: MC-901 Physical volume: Length 88.5, Diameter 26, Section 24mm (measured with precision vernier caliper)
Input parameters: 3.7-7.4V/4A Input line length: about 10 centimeters (red positive, green negative)
Output parameters: 800-1000KV/0.5A Line length: about 16cm
High voltage bipolar discharge distance: 1.5-2 centimeters (strictly prohibited from exceeding)
Product usage: The module is divided into input and output terminals. The red and green wires are the input terminals, with red positive and green negative. The output terminals are two high-voltage wires of the same color. The input terminal can be connected to a battery to generate a high-voltage arc.
Please strictly follow the usage instructions and precautions when operating the module, otherwise it is easy to damage the module!
Regarding input power: 3.7V lithium batteries can be used for input (such as 18650 batteries), nickel cadmium/nickel battery packs, 4V or 6V lead-acid batteries, etc. The input voltage and current affect the output high voltage and arc distance.
