The ZFBT-282-1.5A+ is a high-performance RF/microwave bias device engineered to address critical signal path requirements in sophisticated RF designs. Designed for seamless integration into circuits demanding simultaneous DC power injection and RF signal isolation, this component operates seamlessly across an exceptionally broad frequency spectrum from 10 MHz to 2800 MHz.
+15V for normal operation and -12V for survival rating) at the DC port to a powered RF component (such as an amplifier or active mixer) placed inline on the RF OUTPUT port.Vcc) of up to +15V directly onto the center path. Maximum rated DC current is 1.5A.+30 dBm (1 Watt) across most of its operating band.0.5 dB @ 1 GHz, 1.5 dB @ 2.8 GHz after DC bias adder subtraction), preserving signal integrity throughout the transmission path.0.5 x 0.5 x 02" (LxWxH), ideal for space-constrained assemblies on ceramic-filled PTFE substrate.-40°C to +85°C.The ZFBT-282-1.5A+ is indispensable for RF system designers requiring precise DC biasing for active devices on a signal transmission line without compromising RF integrity. Key applications include:
| Feature | Specification | | :------------------- | :----------------------------- | | Frequency Range | 10 MHz - 2800 MHz | | Operation Voltage| +15V Normal, -12V Survival | | Max DC Current | 1.5A | | Power Handling | +30 dBm CW | | Isolation (ISO) | 20 dB min | | Insertion Loss (Loss) | See datasheet/< 1.5 dB typ. | | Connectors | SMA (IEC 60169-15) | | Package | 0.5" x 0.5 0.2" Metal case | | Temp. Range | -40°C to +85°C |
Engineered and manufactured by Mini-Circuits, a global leader in RF components, the ZFBT-282-1.5A+ stands proven design, verified performance data, and adherence to strict quality standards ensure it will deliver consistent results and enhance the performance of your RF/microwave system through optimized biasing configuration the ZFBT-282-1.5A+ for assured quality and performance.**
